Space Weather Monitor 2.0
202412.12.13.12. 2103Z
SOL91/159C4.6--
MAGAk=6ak=3K=-1
ION85%2.992%-

(updated every 15 minutes - Description)

(Solar data provided by the Space Weather Prediction Center Boulder/CO)

Solar-Wind - Solar-Xray-Proton-Flux - Juliusruh Geomag K/Ak & foF2 - Juliusruh MUF-Monitor - Juliusruh Effective Sunspot Number - Juliusruh Spread-F Monitor - Juliusruh Es-Monitor - Juliusruh Absorption Monitor - Juliusruh Ionograms

Solar Wind Data from ACE Satellite

(Data provided by the US Space Weather Prediction Center Boulder/CO)


Solar X-Ray-, Proton-, Electron-Flux from GOES Satellite(s)

(Data provided by the US Space Weather Prediction Center Boulder/CO)


Juliusruh Geomagnetic Indices and Ionospheric foF2


Juliusruh MUF Monitor

JR055 MUF-Table
13.12.2024 - 21:00 UT
Confidence level: 0
(11-very good, 55-poor)
D[km]MUF(D)[MHz]
0 3.0
100 3.6
200 3.6
400 3.7
600 3.9
800 4.2
1000 4.6
1500 5.8
3000 8.8



Juliusruh Effective Sunspot Number


Juliusruh Spread-F Monitor


Juliusruh Es-Monitor


Juliusruh Absorption Monitor (Under Construction...)


Pruhonice-Juliusruh Monitor (Under Construction)


Description of the Space Weather Monitor

yesterday's day and monthtoday's day and month - update time (Z/UT)
solar activityyesterday's SESC (Boulder/CO) sunspot number R corrected by 0.66 (for better comparison) / predicted monthly sunspot number R12 (green: low solar activity; yellow: moderate sol. act.; red: high sol. act.)highest Xray-flux of the last 2 hours (green: A-, B-, C-class; yellow: M-class; red: X-class)SWF detector if it occurs (green: no SWF; green 'MDE': SWF older than 2 hours; yellow: moderate SWF in the last 2 hours; red: strong SWF in the last two hours; flashing 'MDE': SWF in progress)PCA detector if it occurs (green: no PCA; green 'PCA': PCA ending yesterday; yellow: moderate PCA (E>10MeV); red: strong PCA (E>100MeV); flashing 'PCA': PCA in progress)
geomagnetic activityyesterday's Ak-Index (green: 0-15; yellow: 16-29; red: >=30)today's running Ak-Index (green: 0-15; yellow: 16-29; red: >=30)latest K-Index (green: 0-3; yellow: 4; red: 5-9)(under construction)
ionospheric foF2yesterday's foF2-average relative to the longterm predictionlatest autoscaled vertical incidence foF2-value in MHzrelation between the latest foF2 and longterm predictiondescriptive letter which indicates the reason of an uncertain or impossible measurement (GREEN: accurate value; YELLOW: 'A' blanketing by Es, 'B' absorption, 'D' upper limit of frq.range, 'E' lower limit of frq.range, 'F' spread echoes, 'G' too low ionisation density, 'R' attenuation near foF2, 'S' interference, 'X' deduced from the x-component; RED: 'C' operational problem)
